Introducing the Alta Labs AP6 Pro WiFi 6 access point, which is IP54 rated and features 4096-QAM modulation technology, offering higher throughput rates than other standard access points.

We are an official Alta Labs UK Distributor. Resellers interested in purchasing Alta Labs products, please register a trade account on for information and pricing.

RRP £179 (INC VAT)

Meet the Alta Labs AP6 Pro WiFi 6 access point, the advanced-level access point in the current Alta Labs product lineup. This access point boasts an IP54 rating, making it resistant to small quantities of water and other particulates, ensuring reliable performance even in harsh environments.

The AP6 Pro is also equipped with 4096-QAM modulation technology, which delivers higher throughput rates than other standard access points, enabling you to transfer data faster and more efficiently.

Like its entry-level counterpart, the Alta Labs AP6 Pro features a proprietary antenna design for superior performance, seamless roaming for ultimate convenience, simplified security for easy network protection, and PoE+ powering capabilities.

Thanks to its intelligent mesh formation, the AP6 Pro is mesh-capable, delivering maximum throughput with a combined WiFi capacity of 6.3GB per second. Its QuickMount technology makes it easy to mount on a ceiling or wall.

The Alta Labs AP6 Pro also integrates seamlessly with Alta Labs’ Cloud Management software, enabling you to monitor, configure, and manage your network with ease. The lightweight cloud technology comes with a wide range of features at no additional cost, making it an affordable option for businesses of all sizes.

In summary, the Alta Labs AP6 Pro WiFi 6 access point is the perfect choice for businesses looking for advanced-level performance, reliability, and security. Its IP54 rating and 4096-QAM modulation technology ensure top-of-the-line performance, while its seamless integration with the Alta Labs Cloud Management software makes network management a breeze.


  • Network Interface Ethernet, WiFi, Bluetooth
  • Management Interface (1) GbE RJ45 Port
  • Button(s) Reset/Factory Reset
  • LED Blue, White
  • Power Method PoE+
  • Power Supply PoE+ enabled network switch
  • 48V, 0.5A PoE adapter (optional)
  • Supported Voltage Range 42.5 – 57V DC
  • Maximum Power Consumption 25W
  • Maximum Transmit Power 2.4 GHz: 23 dBm @2NSS
    5 GHz: 26 dBm @4NSS
  • MIMO 2.4 GHz: 2 x 2
    5 GHz: 4 x 4
  • Throughput Rate 2.4 GHz: Up to 573 Mbps
    5 GHz: Up to 5.8 Gbps
  • Antenna Gain 2.4 GHz: Up to 3.3 dBi
    5 GHz: Up to 4.8 dBi


Alta Labs AP6-PRO Datasheet

Alta Labs AP6-PRO Quickstart Guide
